PoE Injector 48V

The ideal solution for applications where an electrical outlet may not be available, this injector adapter can be used to power devices with PoE support, such as PoE IP cameras. The compact, wall-mounted design makes it easy to install the adapter in areas with limited space and can be set up in seconds without the need for configuration.

Applications:

1. IP Phone
2. Wireless Access Point and Client Devices
3. Security Camera System
4. Router/Switchboard
5. POE NVR
6. Network AP
7. Terminals such as AP

Specifications:

• Output: 48 V DC, 500 mA - please do not order if your device requires more than 500 mA
• Input: 100-240 V, 50/60 Hz
• Output: 48 V, 0.5 A
• Input Current: 0.5 A/1 A
• Efficiency: minimum 80%
• Line/Load Regulation: 3% / 5%
• Rotational Speed/Noise: 200 mV p-p
• Startup Delay: maximum 2 seconds
• Rise Time: maximum 40 ms
• Protection: automatic recovery from overvoltage, short circuit, overcurrent
• Operating Temperature: -10 to +40 °C (14 to +104 °F)
• Operating Humidity (RH): 5% to 90%
• Storage Temperature: -20 to +85 °C (-4 to +185 °F)
• Network Connector Type: RJ45 shielded
• PoE Type: Passive PoE (pins 4,5 V+, pins 7,8 V-)
• Provides remote power for equipment via Cat 5 Ethernet cables up to 100 m
• Compatible with 100 ~ 240V AC voltage
• Short circuit, overcurrent, and overvoltage protection
• Reliable 24 W Passive PoE output

Notice:

• The package does not include an RJ45 network cable.
• The product is not waterproof; please pay attention to waterproofing.
• Input voltage range: AC 100 V to 240 V, please use it correctly within the safe range.
• Pay attention to electrical safety.

Package Included:

• 1 * DC 48V, 0.5A POE power supply
