GLEDOPTO GL-C-601P Zigbee Pro Max 5in1 Smart LED Controller

Gledopto GL-C-601P Zigbee Pro Max 5in1

The Gledopto GL-C-601P Zigbee Pro Max is a comprehensive, highly adaptable controller built to manage almost any PWM-dimmable LED strip. Operating on the robust Zigbee 3.0 protocol, it ensures reliable integration with major smart home ecosystems and compatible Zigbee hubs, including Amazon Alexa and Google Assistant.

5-in-1 Versatility and Mix Mode

This smart controller is engineered to support five distinct LED strip configurations: RGBCCT, RGBW, RGB, CCT, and single-color Dimmer modes. A standout feature is the innovative Mix Mode, which allows users to blend colored light and white light in any custom ratio. This provides precise control over 16 million vibrant colors and a tunable white spectrum ranging from a warm 2700K to a crisp 6500K.

Flexible Control Options

The controller offers multiple ways to manage your lighting environment. It can be controlled via smartphone applications or voice commands when connected to a compatible Zigbee hub. Additionally, it supports direct standalone operation using an optional Gledopto 2.4G RF remote or a traditional physical Push Switch, ensuring your lighting remains accessible even without an active hub connection.

Simplified Installation and Power Inputs

Setting up the controller is straightforward due to the upgraded WAGO quick-connect terminals, which allow for secure, tool-free wiring. To accommodate various installation scenarios, the device offers three distinct power input methods: standard V+/V- wire terminals, a 5.5x2.1mm DC barrel socket, and a modern USB Type-C interface.

Advanced Safety and Noise Reduction

Safety and hardware durability are prioritized with a removable 20A pluggable fuse that provides superior overcurrent protection. To eliminate power supply noise, the controller features adjustable PWM frequencies ranging from 600Hz up to 8000Hz. It also includes a power-off memory function that automatically restores your previous lighting state after a power outage.

Technical Parameters
